When do I need a motor filter reactor?

Reactors are typically required when motor cable lengths are extended, when switching frequencies are high, or when driving low-inductance or high-speed motors.

Will a reactor reduce dv/dt and reflected wave voltage?

Yes. A properly specified reactor reduces voltage rise time at the motor terminals and helps suppress reflected wave overvoltage conditions.

Can a reactor improve motor life?

Yes. By reducing insulation stress, current ripple, and thermal loading, a reactor can significantly extend motor service life in high-frequency drive systems.

Does every VFD installation require a reactor?

No. Reactor requirements depend on cable length, motor design, switching frequency, and system architecture. An engineering review is recommended to determine necessity.

Motor Filter Reactors & Chokes

In high-frequency PWM drive systems, motor terminals are exposed to steep voltage rise times (dv/dt), reflected wave overvoltage, and elevated current ripple. These electrical stresses accelerate insulation degradation, increase bearing currents, and elevate thermal loading—especially in low-inductance, high-speed motor applications.

Output Protection for High-Frequency and Long Cable Installations

Motor filter reactors (chokes) enhance motor performance by filtering voltage and current, increasing motor lifespan, and reducing electrical noise. We offer a wide range of reactors for various applications, considering factors like current, voltage, frequency, and wire type. Proper selection is critical to prevent issues, including motor insulation problems.

For motors with long or short wires, motor filter reactors mitigate voltage peaks and dv/dt, extending insulation life. They also reduce motor current ripple, which can vary in impact depending on factors such as motor load, cooling, and duty cycle. Trust our expertise and modern simulation tools for optimal reactor selection to improve your application's performance and reliability.

Get in touch

Frequently asked questions

Motor filter reactors are often misunderstood or incorrectly specified. Below are common technical questions we receive from engineers and plant managers evaluating output filtering for high-frequency drive systems.
